Utilisation
Business
Entreprise
TPE
L3 forwarding
IMIX Traffic:
9.28 Gb/s
IPERF3 Traffic: 8.75 Gb/s
Firewall
IMIX Traffic:
3.21 Gb/s (10k ACLs)
IPERF3 Traffic: 8.61 Gb/s (10k ACLs)
IPsec VPN
IMIX Traffic:
1.05 Gb/s (AES-GCM-128 w/QAT)
IPERF3 Traffic: 3.2 Gb/s (AES-GCM-128 w/QAT)
Chassis
Desktop -
Aluminum, plastic, and steel enclosure. 8.66 x 7.1 x 2.3 inches 220 x 180 x 60
mm
CPU
Intel Atom C1110
with AVX2, 4-core @ 2.1 GHz
CPU Cores
4-Core
Réseau
(4) 2.5 Gbps RJ-45 "direct" (unswitched) ethernet LAN ports
Stockage
16 GB eMMC
(onboard - soldered)
Mémoire
4 GB LPDDR5
Port console
1x auto-detect
console port: "Cisco pinout" RJ45 + micro-USB (micro-USB cable
included with each system)
USB Port
1x USB 3.0 jacks
(USB-A female) Located on right side rear when viewed from system front
LED
3x 3-color LEDs
(RGB) Software / bootloader controllable via GPIO
Refroidissement
Passive -
integrated aluminum chassis and heatsink
Alimentation
AC Inlet:
IEC320-C7 (2 PIN)
EU Power Cord: CEE7/16 to IEC320-C7
External ITE P/S AC/DC 100-240V, 50-60 Hz, 12V 5.0A (60W), threaded (locking)
barrel connector
Divers
Optional wall
mount kit (available soon)
Température de fonctionnement
0°C (32°F) to 40°C (104°F) - ambient
Certifications
CE, CB, FCC (Class B), RoHS, CCATS, UL, RCM, UKCA
