Software
pfSense Plus
Format
Desktop
Utilisation
Business
Particulier, TPE
L3 forwarding
IMIX Traffic:
594 Mb/s
IPERF3 Traffic: 2.20 Gb/s
Firewall
IMIX Traffic:
249 Mb/s (10k ACLs)
IPERF3 Traffic: 964 Mb/s (10k ACLs)
IPsec VPN
IMIX Traffic: 90
Mb/s (AES-GCM-128 / AES-NI w/ SafeXcel)
IPERF3 Traffic: 254 Mb/s (AES-GCM-128 / AES-NI w/ SafeXcel)
CPU
Marvell Armada
3720 (88F3720) ARMv8-A 64-bit Cortex A53 @ 1.2GHz with NEON SIMD and FPU
CPU Cores
Dual Core
Réseau
One 1 Gigabit
Ethernet WAN port (RJ45 / SFP Combo), Four 1 Gigabit Ethernet LAN ports (M
switch, uplink at 2.5 Gbps), LAN ports can be repurposed for additional WAN
ports
Mémoire
4 GB DDR4 (not expandable)
Extension
1x M.2 'B' key
sockets (SSD, LTE), 1x miniPCIe (WiFi), microSIM slot
USB Port
1x 2.0 port
LED
3 full color RGB
LEDs (Pattern info here)
Refroidissement
Passif
Alimentation
Inclus -
External ITE P/S AC/DC 100-240V, 50-60 Hz, 12V 2.0A, threaded barrel connector,
AC Inlet: IEC320-C7 (2 PIN), EU Power Cord: CEE7/16 to IEC320-C7
Température de fonctionnement
32°F (0°C) to 122°F (50°C)
Certifications
CE, FCC (Class B), RoHS, UL, RCM, VCCI
